Compact Track Skid Steer Loader V1000
Higher-capacity compact track loader with vertical lift positioning, heavier operating weight, and a stronger loading profile for contractor fleets.
Where it works
Compact Loading Use Cases
Heavier Compact Loading
Higher-capacity tracked models fit serious contractor work, heavier material handling, and repeated loading cycles where smaller compact loaders fall short.
Farm, Yard, and Utility Support
A larger tracked platform helps with cleanup, feed or bulk handling, ground prep, and daily support tasks on sites with mixed surfaces.
Premium Dealer Lineups
These heavier track loaders give dealers a stronger top-end offering for buyers comparing payload, chassis size, and loading height.
Key points
What Buyers Usually Check
V1000 moves into a more serious tracked-loader class with higher rated load and broader loading reach.
The page combines clear machine views with a stronger parameter set, making it more useful than an image-only listing.
A practical option for buyers who need a loader above entry compact size but below the biggest V2000 platform.
Full specifications
V1000
| Operating weight | 1417 kg |
| Bucket capacity | 0.19 m3 |
| Climbing ability | 25 deg |
| Maximum breakout force | 4.5 kN |
| Rated load | 500 kg |
| Maximum load | 650 kg |
| Travel speed | 0-4.5 km/h |
| Working system pressure | 19.5 MPa |
| Bucket width | 1235 mm |
| Max loading height | 1740 mm |
| Max dumping height | 1522 mm |
| Max operating height | 2794 mm |
| Max height bucket dump angle | 63 deg |
| Ground clearance | 200 mm |
| Dumping distance | 498 mm |
| Track contact length | 1026 mm |
| Overall dimensions | 2691 x 1235 x 1548 mm |
| Track shoe | 230 x 72 x 45 |
| Engine | Yanmar / Kubota 3TNV80 / D1105 |
| Rated power | 17.8 / 18.5 kW |
| Emission standard | EPA / EURO5 |
| Fuel tank capacity | 40 L |
Other models
Skid Steer Loader Range
450 kg | 0.22 m3
Skid Steer Loader 25
Small enclosed skid steer with solid tires, compact width, and light loading support for paved yards and confined sites.
886 kg | 0.4 m3
Skid Steer Loader S55
Closed-cab wheel loader with 0.4 m3 bucket, higher rated load, and faster travel for daily support work.
Track | High Tip
Compact Track Skid Steer Loader C1200
Red compact track loader media set with high-tip action, narrow-access framing, and general loading support positioning.
Mixer Setup | C1200
Skid Steer Loader C1200 Mixing Attachment
C1200 mixing configuration for compact batching, material prep, and narrow-access concrete workflows.
200 kg | 0.1 m3
Mini Skid Steer S360
Compact wheeled mini skid steer with reinforced tires, light rated load, and simple small-site support positioning.
180 kg | 0.07 m3
Mini Skid Steer S370
Wheeled loader with 0.07 m3 bucket, easy-control positioning, and higher travel speed for small-site work.
Quote
Quote V1000
Email info@terracub.com or send a WhatsApp message with your quantity, project region, and application details.
